Packaging - Caractéristiques
Lorsque vous achetez une carte mere, que vous le vouliez ou non, vous voyez d'abord la boite :) Autant que celle-ci soie nette et quelle contienne tout le necessaire afin qu'on puisse directement profiter du contenu !
Premiere surprise, la boite represente une AB30 de Shuttle, carte mére equipée de l'i845 d'Intel ! En fait, aucun texte n'apparait sur la boite pour indiquer ce quelle contient. Cependant, un gros autocollant "P4X266" collé sur le dessus nous rapelle de quoi il s'agit. Outre la carte mère, la boite contient le minimum vital :
- une nappe 34 connecteurs ( disquette )
- une nappe 80 connecteurs IDE UDMA66/100
- une petite carte avec deux ports USB supplementaires
- un CD-ROM de drivers
- un manuel
De meme, le manuel indique clairement "AV40/AV40R - Socket 478 - Pentium 4 processor based DDR Main board" mais nous montre la photo de la carte i845/SDRAM ! Heureusement, le manuel correspond bien à la carte en question !
Un mot sur l'installation : elle s'est déroulée sans probleme, cependant il faut une alimentation compatible ATX 2.03 qui dispose de 3 connecteurs d'alimentations pour la carte mère ( le principal et les deux auxilliaires ). Inute d'essayer sans ces deux auxilliaires, ca ne fonctionne pas, nous avons essayé...
- Caractéristiques de la carte
Bon, la, on va fainéanter un peu et on va vous recopier les caractéristiques de la carte selon Shuttle :
| Type de CPU Supporté
: Socket 478 |
| Intel Pentium 4 - Socket 478 pins |
| Chipsets: VIA P4X266 |
| (North) VIA P4X266: Support Pentium 4 System bus Support DDR 200 / 266 SDRAM interface Support AGP interface Support V-Link interface to VT8233 Support ACPI 1.0b compliant power management Support APM 1.2 compliant power management (South) VIA VT8233 Built in high bandwidth 266MB/S 8-bit V-link Host controller Integrated USB controller with three root hub and six function ports Integrated dual channel UDMA 33/66/100 master mode EIDE controller LPC interface for Low Pin Count interface to Super-I/O or ROM Integrated Keyboard Controller with PS2 mouse support Integrated DS12885-style Real Time Clock with extended 256 byte CMOS RAM and Day/Month Alarm for ACPI System Management Bus Interface Sophisticated PC99-Compatible Mobile Power Management Integrated Plug and Play Controller |
| Form Factor |
| ATX |
| Front Side Bus |
| 100 / 133MHz (Bios adjustable) |
| Memory |
| Support DDR 200/266 compliant SDRAM up to 1.5GB (un-buffered) capacity Support DDR 200/266 compliant SDRAM up to 3GB (registered) capacity |
| Audio: AC97 audio |
| AC'97 2.1 compliant CODEC on board |
| Expansion Slot:1 x AGP 2.0
compliant slot |
| Support external AGP V2.0 compliant VGA device Support 1.5V AGP electrical only Support 1X, 2X, 4X AGP data transfer 5 x PCI slots PCI 2.2 compliant, 32-bit BUS Master Slots 133 Mbyte / sec maximum throughput |
| LPC I/O:ITE 8705F |
| Comply with Intel Low Pin Count Interface Specification Rev. 1.0 ACPI V. 1.0 compliant Built in H/W monitor feature Two 16C550 UARTs Supports two standard Serial Ports Supports IrDA 1.0/ASKIR protocols Supports Smart Card Reader protocols Built in Smart Card Reader IEEE 1284 Parallel Port Standard mode -- Bi-directional SPP compliant Enhanced mode -- EPP V. 1.7 and V. 1.9 compliant High speed mode -- ECP, IEEE 1284 compliant Floppy Disk Controller Supports two 360K/ 720K/ 1.2M/ 1.44M/ 2.88M floppy disk drives Enhanced digital data separator 3-Mode drives supported Keyboard Controller Game Port Dedicated MIDI Interface Support power-failure resume and power button de-bounce |
| H/W Monitoring : Built in
ITE 8705F |
| 2 thermal inputs from remote thermal resistor to monitor system
temperature 1 thermal input from thermal diode to monitor CPU temperature 8 voltage monitor inputs 1 chassis intrusion input Monitors 3 fan tachometer inputs Smart Guardian Controller to provide programmable fan speed automatic control |
| Power Management |
| APM 1.2 compliant ACPI 1.0 compliant Support multiple system suspend types - suspend to DRAM, suspend to disk, and all with hardware automatic wake-up |
| Bios: Award PnP BIOS |
| Stored in 2 Mb flash memory DMI 2.3 CPU 100 / 133MHz FSB setting BIOS FSB step-less setting from 100MHz to 166MHz with 1 MHz increment CPU core voltage setting from +0.025V ~ +0.20V AGP (Vddq) voltage setting from +0.05V ~ +0.20V I/O voltage setting from +0.1V ~0.2V Support IRQ manual assign table Bootable from Floppy, ATAPI device, USB device, SCSI device |
| On Board Ports / Connectors
/ Jumpers / Headers (front/back panel): Ports |
| Back Panel: 2 Serial Ports 1 Parallel Port (SPP, EPP, ECP) 1 PS/2 Keyboard Port 1 PS/2 Mouse Port 2 USB Ports 1x Game / MIDI Port 1x Line in, 1x Line out, 1x Mic Connectors: 1 x ATX power connector 1 x 4 pin 12V ATX power connector 1 x 6 pin 5V / 3.3V ATX power connector 4 x Fan Power connectors (one for system chipset fan) 4 x UltraDMA/100 Bus Master IDE (2 RAID IDE optional) 1 x Floppy Jumpers: Clear CMOS BIOS Boot block protection Headers: 2 sets of 2 x5 pin Front Panel USB header (1 set is from ISL1561 by optional) Mini CD Audio in TAD in CD Audio in Other Features: Suspend switch and LED |
